Acoustic Communication

Have you ever thought about how sea creatures like whales talk to each other over long distances in the ocean, or how bats see in the dark using sounds?  Imagine a world where data transmission doesn't rely on electromagnetic waves but travels through air, water, or even solid materials using sound waves.This idea is real and it's called Acoustic Communication. It's a new way to send data using sound waves.

But what is Acoustic Communication really about, and why is it important for us today? How can this old way of sending messages, which sea animals have used for a very long time, help us solve new problems in how we connect with technology? Let's start exploring Acoustic Communication together. In this note, We'll look at what it is, how it works, and how it could change the way our devices connect in the future.

Followings are what I am going to cover in this note

Acoustic Communication in Animal worlds

The main purpose of this note does not lies in the bio communication, but I thought it would be good  to take a look at some examples of utilizing acoustic communication in nature before we look into the application to the communication for human.

Acoustic communication in the animal world is a fascinating subject, rich in diversity and complexity. Animals use sound to convey information for various purposes, including mating calls, territory defense, social interactions, and navigation. The technical aspects of these sounds—such as waveform, frequency, and whether they are pulse or continuous waves—vary widely across species. Here are detailed examples from a few notable cases:

  • Bats (Echolocation)
    • Frequency: Bats emit echolocation calls that can range from 14 kHz to well over 100 kHz, far beyond human hearing (which caps at about 20 kHz). The specific frequency depends on the bat species and the environmental context (e.g., hunting, navigating through dense foliage).
    • Waveform: Echolocation calls often start at a higher frequency and sweep down to a lower frequency. This broad range helps in precisely determining the distance and size of objects.
    • Type: Bats use both pulse and continuous waves, but most echolocation falls into the pulse category, with bats emitting short, sharp bursts of sound. The interval between pulses and the pulse duration can provide information about the bat's environment and its prey.
    • Range: The effective range of bat echolocation can vary widely, from just a few meters for small insectivorous bats navigating through dense vegetation, to over 100 meters for some species hunting in open spaces. The range is influenced by the frequency of the call (higher frequencies attenuate more rapidly) and the surrounding environment
    • Power: The intensity of bat echolocation calls can vary significantly, but some species emit calls that can reach up to 120-140 decibels at the source. The power of these calls enables the bats to detect and navigate around objects as small as insects, even in complete darkness.
  • Whales (Long-distance Communication)
    • Frequency: Whale songs, particularly those of the humpback whale, can range from 20 Hz to 20 kHz. Lower frequencies are used for long-distance communication, as they travel further in the underwater environment.
    • Waveform: Whale songs can be incredibly complex, with patterns that include moans, cries, and whistles. The songs of humpback whales, for example, are structured and can last for hours, repeating patterns of moans, roars, and chirps.
    • Type: Whales use continuous waves in their songs, which can last from a few minutes to over 20 minutes in some species. These songs are thought to play a role in mating and social bonding.
    • Range: Whales, especially those species known for their long, low-frequency calls like the blue whale and fin whale, can communicate over astonishing distances, up to hundreds or even thousands of kilometers in ideal underwater conditions. This is facilitated by the so-called "deep sound channel," which allows low-frequency sounds to travel great distances with minimal loss of energy.
    • Power: The vocalizations of large whales, especially those of the blue whale, are among the most powerful biological sounds known. These calls can reach levels of 180-190 decibels and sometimes even higher. The immense power of these calls, combined with their low frequency, allows them to propagate across hundreds or even thousands of kilometers under the right oceanic conditions.
  • Dolphins (Social Interaction and Navigation)
    • Frequency: Dolphin sounds vary widely, with clicks for echolocation typically ranging from 20 kHz to 150 kHz and whistles for communication falling between 0.2 kHz to 20 kHz.
    • Waveform: Dolphins produce a variety of sounds including clicks, burst-pulse sounds, and whistles. Clicks are used for echolocation, while whistles are primarily for communication.
    • Type: Echolocation clicks are short, high-frequency pulse sounds, whereas communication sounds like whistles can be considered continuous waves with varying pitch and amplitude.
    • Range: Dolphins' echolocation clicks typically have a range of up to about 100 meters, but this can vary based on the purpose (e.g., foraging vs. navigation). Social sounds like whistles and burst-pulse sounds can be heard by other dolphins up to several kilometers away under favorable conditions.
    • Power: Dolphin echolocation clicks are also quite powerful, with sound pressure levels reaching 220 decibels or more at the source. This high intensity is crucial for the high-resolution echolocation that dolphins use for hunting and navigating in murky waters.
  • Elephant Communication(Long-distance Communication and Social Coordination)
    • Frequency: Elephants communicate using low-frequency sounds, called infrasound, ranging from 14 Hz to 35 Hz, which are below the range of human hearing.
    • Waveform: These low-frequency sounds have long wavelengths, allowing them to travel great distances through dense forest or across the savannah. The waveforms can be complex, including rumbles, roars, and trumpets.
    • Type: Primarily, elephants use pulse waves for communication. These infrasonic communications can be continuous rumbles or pulses for different social interactions.
    • Range: The communication range for elephants can extend over several kilometers, up to 10 km or more under optimal conditions, facilitating long-distance communication within herds and between herds.
  • Insects (Mating Calls)
    • Frequency: The frequency of insect sounds can vary significantly, with some cricket species producing sounds at frequencies around 3-5 kHz, which is within the range of human hearing.
    • Waveform: Insects like crickets and cicadas produce sounds by stridulation, which involves rubbing parts of their bodies together. The resulting sound waveform is typically a repetitive, rhythmic pulse that can vary in intensity and speed.
    • Type: These are typically pulse waves, with the rhythm and repetition rate often playing a crucial role in species recognition and mate selection.
    • Range: The range of insect acoustic communication is much more limited compared to marine mammals or bats, generally extending from a few meters to a few hundred meters, depending on the species and the environment. For example, the common field cricket's call can be heard up to 50-60 meters away, but this range can be affected by vegetation, terrain, and ambient noise.
    • Power: Insects, due to their small size, produce sounds at much lower absolute power levels than larger animals. However, relative to their size, these sounds can be quite intense. For example, a male cicada can produce sounds in the range of 90-100 decibels at close range, which is remarkably loud given the small size of the sound-producing mechanism.

Acoustic Communication in Human Technology

Acoustic communication in human technology involves the use of sound waves to transmit information across distances, similar to methods observed in the animal kingdom, but engineered to serve specific human needs. Here are detailed examples of acoustic communication technologies, focusing on their technical aspects such as waveform, frequencies, and whether they are pulse or continuous waves, similar to the animal examples provided earlier.

  • Sonar (Sound Navigation and Ranging)
    • Used By:  Submarines, ships, and some fishing vessels.
    • Frequency:  Sonar systems operate over a wide range of frequencies, typically from a few kHz for long-range detection up to hundreds of kHz for high-resolution mapping and close-range detection.
    • Waveform:  Sonar systems can emit both pulse and continuous waveforms. Pulse waveforms are short bursts of sound used to measure distances by timing the echo's return, while continuous waveforms can be used for velocity measurement and are often employed in Doppler sonar systems.
    • Power:  The intensity of sonar signals can vary greatly, with some military sonar systems capable of producing sounds over 235 decibels.
  • Ultrasonic Sensors
    • Used By:  Industrial sensors, automotive parking aids, and medical imaging devices.
    • Frequency:  These sensors typically operate in the ultrasonic range, from 20 kHz up to several MHz. The exact frequency depends on the application, with higher frequencies providing finer resolution.
    • Waveform:  Ultrasonic sensors usually use pulse waves to measure distance or detect objects, similar to echolocation in bats.
    • Power:  The power output is generally lower than that of sonar systems, tailored to the sensor's specific use case, ranging from a few milliwatts to several watts.
  • Acoustic Modems (Underwater Communication)
    • Used By:  Underwater vehicles, divers, and data collection buoys.
    • Frequency:  These modems use frequencies typically between 1 kHz and 30 kHz, allowing communication over several kilometers underwater, where higher frequencies would be absorbed quickly.
    • Waveform:  They employ complex modulation schemes to encode data onto sound waves, including both pulse and continuous waveforms, depending on the data rate and distance.
    • Power:  The transmission power can range from less than a watt for short-range communication to tens or hundreds of watts for long-distance communication.
  • Hearing Aids and Cochlear Implants
    • Used By:  Individuals with hearing impairments.
    • Frequency:  These devices are designed to amplify sounds in the frequency range most important for understanding speech, typically from 250 Hz to 6 kHz.
    • Waveform:  They process continuous sound waves from the environment, amplifying or digitally enhancing specific frequencies to improve the user's hearing ability.
    • Power:  The power output is very low, optimized for close-range auditory assistance, usually just a few milliwatts.

Technical Factors for Acoustic Communication

Acoustic communication involves using sound to send and receive messages, a method used by both animals and humans. To understand how it works, we need to look at some important technical factors. These include how sound is made, how it travels through different environments like air or water, and how it is heard by the receiver. This exploration helps us learn from nature, such as how bats or whales use sound. It also helps us make better technology, like machines that use sound to see underwater or devices that help people hear better. Understanding these technical parts is key to improving how we use sound for communication

  • Key Influences on Sound Travel: Medium, Speed, and Environment
    • Propagation Medium: The medium (air, water) significantly affects the propagation of sound waves. Water, for example, carries low-frequency sounds over much longer distances than air, which is why many aquatic animals use low frequencies for communication.
    • Sound Speed: The speed of sound is also medium-dependent, being faster in water (approximately 1500 meters/second) than in air (approximately 343 meters/second at sea level). This affects how animals time their calls and listen for echoes.
    • Environmental Factors: Temperature, humidity, and atmospheric pressure can affect sound transmission and are considered by animals, either instinctively or through learned behavior, to optimize communication.
  • Factors Influencing Range
    • Environmental Acoustics: Open environments like the ocean or air can carry sounds over longer distances than dense environments like forests or underwater with lots of structures.
    • Frequency and Power: Generally, lower frequencies can travel longer distances due to less attenuation, and louder sounds can also extend the range of communication.
    • Atmospheric and Water Conditions: Temperature, humidity, wind, and water currents can affect sound propagation, either enhancing or reducing the distance over which it can travel.
    • Background Noise: High levels of ambient noise can reduce the effective range of acoustic signals, a phenomenon increasingly relevant due to human-generated noise pollution.
  • Factors Influencing Power
    • Environmental Impact: The effectiveness and power of an acoustic signal are also influenced by the environment through which it travels. For instance, sound propagates more efficiently in water than in air, allowing marine animals to communicate over greater distances with less power loss.
    • Perception: The perceived loudness or power of a sound can also depend on the sensitivity of the receiver's hearing. Animals have evolved to produce sounds within the most sensitive range of their intended audience's hearing.

Challenges

Acoustic communication technology has opened new horizons in how we interact with and understand the world around us. However, it also faces a multitude of challenges that can affect its efficiency and reliability. From environmental interference to technological limitations, these obstacles require innovative solutions to ensure that acoustic signals can be transmitted and received effectively, facilitating seamless communication across various applications. Followings a list of well known limitation in Acoustic communication.

  • Signal Attenuation: Loss of signal strength over distance, especially in complex environments.
  • Noise Interference: Background noise can significantly degrade signal quality and intelligibility.
  • Multipath Propagation: Reflections from surfaces cause multiple paths of signal, leading to interference and signal distortion.
  • Limited Bandwidth: The range of frequencies available for acoustic communication is often limited, affecting data transmission rates.
  • Environmental Variability: Changes in temperature, humidity, and pressure can alter sound speed and propagation characteristics.
  • Power Consumption: High power may be required for generating and transmitting acoustic signals over long distances.
  • Hardware Limitations: The design and quality of transducers (microphones and speakers) limit the effectiveness and efficiency of acoustic communication systems.
