Quick Reference - Band/ARFCN/Frequency Map









< 45.005 Table 2-2 Fixed designation of ARFCN >

Band

Uplink Frequency

ARFCN

Downlink Frequency

P-GSM 900

Fl(n) = 890 + 0.2*n

1 <= n <= 124

Fu(n) = Fl(n) + 45

E-GSM 900

Fl(n) = 890 + 0.2*n

Fl(n) = 890 + 0.2*(n-1024)

0 <= n <= 124

975 <= n <= 1023

Fu(n) = Fl(n) + 45

R-GSM 900

Fl(n) = 890 + 0.2*n

Fl(n) = 890 + 0.2*(n-1024)

0 <= n <= 124

955 <= n <= 1023

Fu(n) = Fl(n) + 45

DCS 1800

Fl(n) = 1710.2 + 0.2*(n-512)

512 <= n <= 885

Fu(n) = Fl(n) + 95

PCS 1900

Fl(n) = 1850.2 + 0.2*(n-512)

512 <= n <= 810

Fu(n) = Fl(n) + 80

GSM 450

Fl(n) = 450.6 + 0.2*(n-259)

259 <= n <= 293

Fu(n) = Fl(n) + 10

GSM 480

Fl(n) = 479 + 0.2*(n-306)

306 <= n <= 340

Fu(n) = Fl(n) + 10

GSM 850

Fl(n) = 824.2 + 0.2*(n-128)

128 <= n <= 251

Fu(n) = Fl(n) + 45





< 45.005 Table 2-1 Dynamically mapped ARFCN >





< Frequency Table for P-GSM 900>

ARFCN

fl(UL)

fu(DL)

1

890.2

935.2

2

890.4

935.4

3

890.6

935.6

4

890.8

935.8

5

891.0

936.0

6

891.2

936.2

7

891.4

936.4

8

891.6

936.6

9

891.8

936.8

10

892.0

937.0

11

892.2

937.2

12

892.4

937.4

13

892.6

937.6

14

892.8

937.8

15

893.0

938.0

16

893.2

938.2

17

893.4

938.4

18

893.6

938.6

19

893.8

938.8

20

894.0

939.0

21

894.2

939.2

22

894.4

939.4

23

894.6

939.6

24

894.8

939.8

25

895.0

940.0

26

895.2

940.2

27

895.4

940.4

28

895.6

940.6

29

895.8

940.8

30

896.0

941.0

31

896.2

941.2

32

896.4

941.4

33

896.6

941.6

34

896.8

941.8

35

897.0

942.0

36

897.2

942.2

37

897.4

942.4

38

897.6

942.6

39

897.8

942.8

40

898.0

943.0

41

898.2

943.2

42

898.4

943.4

43

898.6

943.6

44

898.8

943.8

45

899.0

944.0

46

899.2

944.2

47

899.4

944.4

48

899.6

944.6

49

899.8

944.8

50

900.0

945.0

51

900.2

945.2

52

900.4

945.4

53

900.6

945.6

54

900.8

945.8

55

901.0

946.0

56

901.2

946.2

57

901.4

946.4

58

901.6

946.6

59

901.8

946.8

60

902.0

947.0

61

902.2

947.2

62

902.4

947.4

63

902.6

947.6

64

902.8

947.8

65

903.0

948.0

66

903.2

948.2

67

903.4

948.4

68

903.6

948.6

69

903.8

948.8

70

904.0

949.0

71

904.2

949.2

72

904.4

949.4

73

904.6

949.6

74

904.8

949.8

75

905.0

950.0

76

905.2

950.2

77

905.4

950.4

78

905.6

950.6

79

905.8

950.8

80

906.0

951.0

81

906.2

951.2

82

906.4

951.4

83

906.6

951.6

84

906.8

951.8

85

907.0

952.0

86

907.2

952.2

87

907.4

952.4

88

907.6

952.6

89

907.8

952.8

90

908.0

953.0

91

908.2

953.2

92

908.4

953.4

93

908.6

953.6

94

908.8

953.8

95

909.0

954.0

96

909.2

954.2

97

909.4

954.4

98

909.6

954.6

99

909.8

954.8

100

910.0

955.0

101

910.2

955.2

102

910.4

955.4

103

910.6

955.6

104

910.8

955.8

105

911.0

956.0

106

911.2

956.2

107

911.4

956.4

108

911.6

956.6

109

911.8

956.8

110

912.0

957.0

111

912.2

957.2

112

912.4

957.4

113

912.6

957.6

114

912.8

957.8

115

913.0

958.0

116

913.2

958.2

117

913.4

958.4

118

913.6

958.6

119

913.8

958.8

120

914.0

959.0

121

914.2

959.2

122

914.4

959.4

123

914.6

959.6

124

914.8

959.8





< Frequency Table for E-GSM 900>

ARFCN

fl(UL)

fu(DL)

0

890.0

935.0

1

890.2

935.2

2

890.4

935.4

3

890.6

935.6

4

890.8

935.8

5

891.0

936.0

6

891.2

936.2

7

891.4

936.4

8

891.6

936.6

9

891.8

936.8

10

892.0

937.0

11

892.2

937.2

12

892.4

937.4

13

892.6

937.6

14

892.8

937.8

15

893.0

938.0

16

893.2

938.2

17

893.4

938.4

18

893.6

938.6

19

893.8

938.8

20

894.0

939.0

21

894.2

939.2

22

894.4

939.4

23

894.6

939.6

24

894.8

939.8

25

895.0

940.0

26

895.2

940.2

27

895.4

940.4

28

895.6

940.6

29

895.8

940.8

30

896.0

941.0

31

896.2

941.2

32

896.4

941.4

33

896.6

941.6

34

896.8

941.8

35

897.0

942.0

36

897.2

942.2

37

897.4

942.4

38

897.6

942.6

39

897.8

942.8

40

898.0

943.0

41

898.2

943.2

42

898.4

943.4

43

898.6

943.6

44

898.8

943.8

45

899.0

944.0

46

899.2

944.2

47

899.4

944.4

48

899.6

944.6

49

899.8

944.8

50

900.0

945.0

51

900.2

945.2

52

900.4

945.4

53

900.6

945.6

54

900.8

945.8

55

901.0

946.0

56

901.2

946.2

57

901.4

946.4

58

901.6

946.6

59

901.8

946.8

60

902.0

947.0

61

902.2

947.2

62

902.4

947.4

63

902.6

947.6

64

902.8

947.8

65

903.0

948.0

66

903.2

948.2

67

903.4

948.4

68

903.6

948.6

69

903.8

948.8

70

904.0

949.0

71

904.2

949.2

72

904.4

949.4

73

904.6

949.6

74

904.8

949.8

75

905.0

950.0

76

905.2

950.2

77

905.4

950.4

78

905.6

950.6

79

905.8

950.8

80

906.0

951.0

81

906.2

951.2

82

906.4

951.4

83

906.6

951.6

84

906.8

951.8

85

907.0

952.0

86

907.2

952.2

87

907.4

952.4

88

907.6

952.6

89

907.8

952.8

90

908.0

953.0

91

908.2

953.2

92

908.4

953.4

93

908.6

953.6

94

908.8

953.8

95

909.0

954.0

96

909.2

954.2

97

909.4

954.4

98

909.6

954.6

99

909.8

954.8

100

910.0

955.0

101

910.2

955.2

102

910.4

955.4

103

910.6

955.6

104

910.8

955.8

105

911.0

956.0

106

911.2

956.2

107

911.4

956.4

108

911.6

956.6

109

911.8

956.8

110

912.0

957.0

111

912.2

957.2

112

912.4

957.4

113

912.6

957.6

114

912.8

957.8

115

913.0

958.0

116

913.2

958.2

117

913.4

958.4

118

913.6

958.6

119

913.8

958.8

120

914.0

959.0

121

914.2

959.2

122

914.4

959.4

123

914.6

959.6

124

914.8

959.8

975

880.2

925.2

976

880.4

925.4

977

880.6

925.6

978

880.8

925.8

979

881.0

926.0

980

881.2

926.2

981

881.4

926.4

982

881.6

926.6

983

881.8

926.8

984

882.0

927.0

985

882.2

927.2

986

882.4

927.4

987

882.6

927.6

988

882.8

927.8

989

883.0

928.0

990

883.2

928.2

991

883.4

928.4

992

883.6

928.6

993

883.8

928.8

994

884.0

929.0

995

884.2

929.2

996

884.4

929.4

997

884.6

929.6

998

884.8

929.8

999

885.0

930.0

1000

885.2

930.2

1001

885.4

930.4

1002

885.6

930.6

1003

885.8

930.8

1004

886.0

931.0

1005

886.2

931.2

1006

886.4

931.4

1007

886.6

931.6

1008

886.8

931.8

1009

887.0

932.0

1010

887.2

932.2

1011

887.4

932.4

1012

887.6

932.6

1013

887.8

932.8

1014

888.0

933.0

1015

888.2

933.2

1016

888.4

933.4

1017

888.6

933.6

1018

888.8

933.8

1019

889.0

934.0

1020

889.2

934.2

1021

889.4

934.4

1022

889.6

934.6

1023

889.8

934.8





< Frequency Table for R-GSM 900>

ARFCN

fl(UL)

fu(DL)

0

890.0

935.0

1

890.2

935.2

2

890.4

935.4

3

890.6

935.6

4

890.8

935.8

5

891.0

936.0

6

891.2

936.2

7

891.4

936.4

8

891.6

936.6

9

891.8

936.8

10

892.0

937.0

11

892.2

937.2

12

892.4

937.4

13

892.6

937.6

14

892.8

937.8

15

893.0

938.0

16

893.2

938.2

17

893.4

938.4

18

893.6

938.6

19

893.8

938.8

20

894.0

939.0

21

894.2

939.2

22

894.4

939.4

23

894.6

939.6

24

894.8

939.8

25

895.0

940.0

26

895.2

940.2

27

895.4

940.4

28

895.6

940.6

29

895.8

940.8

30

896.0

941.0

31

896.2

941.2

32

896.4

941.4

33

896.6

941.6

34

896.8

941.8

35

897.0

942.0

36

897.2

942.2

37

897.4

942.4

38

897.6

942.6

39

897.8

942.8

40

898.0

943.0

41

898.2

943.2

42

898.4

943.4

43

898.6

943.6

44

898.8

943.8

45

899.0

944.0

46

899.2

944.2

47

899.4

944.4

48

899.6

944.6

49

899.8

944.8

50

900.0

945.0

51

900.2

945.2

52

900.4

945.4

53

900.6

945.6

54

900.8

945.8

55

901.0

946.0

56

901.2

946.2

57

901.4

946.4

58

901.6

946.6

59

901.8

946.8

60

902.0

947.0

61

902.2

947.2

62

902.4

947.4

63

902.6

947.6

64

902.8

947.8

65

903.0

948.0

66

903.2

948.2

67

903.4

948.4

68

903.6

948.6

69

903.8

948.8

70

904.0

949.0

71

904.2

949.2

72

904.4

949.4

73

904.6

949.6

74

904.8

949.8

75

905.0

950.0

76

905.2

950.2

77

905.4

950.4

78

905.6

950.6

79

905.8

950.8

80

906.0

951.0

81

906.2

951.2

82

906.4

951.4

83

906.6

951.6

84

906.8

951.8

85

907.0

952.0

86

907.2

952.2

87

907.4

952.4

88

907.6

952.6

89

907.8

952.8

90

908.0

953.0

91

908.2

953.2

92

908.4

953.4

93

908.6

953.6

94

908.8

953.8

95

909.0

954.0

96

909.2

954.2

97

909.4

954.4

98

909.6

954.6

99

909.8

954.8

100

910.0

955.0

101

910.2

955.2

102

910.4

955.4

103

910.6

955.6

104

910.8

955.8

105

911.0

956.0

106

911.2

956.2

107

911.4

956.4

108

911.6

956.6

109

911.8

956.8

110

912.0

957.0

111

912.2

957.2

112

912.4

957.4

113

912.6

957.6

114

912.8

957.8

115

913.0

958.0

116

913.2

958.2

117

913.4

958.4

118

913.6

958.6

119

913.8

958.8

120

914.0

959.0

121

914.2

959.2

122

914.4

959.4

123

914.6

959.6

124

914.8

959.8

955

876.2

921.2

956

876.4

921.4

957

876.6

921.6

958

876.8

921.8

959

877.0

922.0

960

877.2

922.2

961

877.4

922.4

962

877.6

922.6

963

877.8

922.8

964

878.0

923.0

965

878.2

923.2

966

878.4

923.4

967

878.6

923.6

968

878.8

923.8

969

879.0

924.0

970

879.2

924.2

971

879.4

924.4

972

879.6

924.6

973

879.8

924.8

974

880.0

925.0

975

880.2

925.2

976

880.4

925.4

977

880.6

925.6

978

880.8

925.8

979

881.0

926.0

980

881.2

926.2

981

881.4

926.4

982

881.6

926.6

983

881.8

926.8

984

882.0

927.0

985

882.2

927.2

986

882.4

927.4

987

882.6

927.6

988

882.8

927.8

989

883.0

928.0

990

883.2

928.2

991

883.4

928.4

992

883.6

928.6

993

883.8

928.8

994

884.0

929.0

995

884.2

929.2

996

884.4

929.4

997

884.6

929.6

998

884.8

929.8

999

885.0

930.0

1000

885.2

930.2

1001

885.4

930.4

1002

885.6

930.6

1003

885.8

930.8

1004

886.0

931.0

1005

886.2

931.2

1006

886.4

931.4

1007

886.6

931.6

1008

886.8

931.8

1009

887.0

932.0

1010

887.2

932.2

1011

887.4

932.4

1012

887.6

932.6

1013

887.8

932.8

1014

888.0

933.0

1015

888.2

933.2

1016

888.4

933.4

1017

888.6

933.6

1018

888.8

933.8

1019

889.0

934.0

1020

889.2

934.2

1021

889.4

934.4

1022

889.6

934.6

1023

889.8

934.8





< Frequency Table for DCS 1800>

ARFCN

fl(UL)

fu(DL)

512

1710.2

1805.2

513

1710.4

1805.4

514

1710.6

1805.6

515

1710.8

1805.8

516

1711.0

1806.0

517

1711.2

1806.2

518

1711.4

1806.4

519

1711.6

1806.6

520

1711.8

1806.8

521

1712.0

1807.0

522

1712.2

1807.2

523

1712.4

1807.4

524

1712.6

1807.6

525

1712.8

1807.8

526

1713.0

1808.0

527

1713.2

1808.2

528

1713.4

1808.4

529

1713.6

1808.6

530

1713.8

1808.8

531

1714.0

1809.0

532

1714.2

1809.2

533

1714.4

1809.4

534

1714.6

1809.6

535

1714.8

1809.8

536

1715.0

1810.0

537

1715.2

1810.2

538

1715.4

1810.4

539

1715.6

1810.6

540

1715.8

1810.8

541

1716.0

1811.0

542

1716.2

1811.2

543

1716.4

1811.4

544

1716.6

1811.6

545

1716.8

1811.8

546

1717.0

1812.0

547

1717.2

1812.2

548

1717.4

1812.4

549

1717.6

1812.6

550

1717.8

1812.8

551

1718.0

1813.0

552

1718.2

1813.2

553

1718.4

1813.4

554

1718.6

1813.6

555

1718.8

1813.8

556

1719.0

1814.0

557

1719.2

1814.2

558

1719.4

1814.4

559

1719.6

1814.6

560

1719.8

1814.8

561

1720.0

1815.0

562

1720.2

1815.2

563

1720.4

1815.4

564

1720.6

1815.6

565

1720.8

1815.8

566

1721.0

1816.0

567

1721.2

1816.2

568

1721.4

1816.4

569

1721.6

1816.6

570

1721.8

1816.8

571

1722.0

1817.0

572

1722.2

1817.2

573

1722.4

1817.4

574

1722.6

1817.6

575

1722.8

1817.8

576

1723.0

1818.0

577

1723.2

1818.2

578

1723.4

1818.4

579

1723.6

1818.6

580

1723.8

1818.8

581

1724.0

1819.0

582

1724.2

1819.2

583

1724.4

1819.4

584

1724.6

1819.6

585

1724.8

1819.8

586

1725.0

1820.0

587

1725.2

1820.2

588

1725.4

1820.4

589

1725.6

1820.6

590

1725.8

1820.8

591

1726.0

1821.0

592

1726.2

1821.2

593

1726.4

1821.4

594

1726.6

1821.6

595

1726.8

1821.8

596

1727.0

1822.0

597

1727.2

1822.2

598

1727.4

1822.4

599

1727.6

1822.6

600

1727.8

1822.8

601

1728.0

1823.0

602

1728.2

1823.2

603

1728.4

1823.4

604

1728.6

1823.6

605

1728.8

1823.8

606

1729.0

1824.0

607

1729.2

1824.2

608

1729.4

1824.4

609

1729.6

1824.6

610

1729.8

1824.8

611

1730.0

1825.0

612

1730.2

1825.2

613

1730.4

1825.4

614

1730.6

1825.6

615

1730.8

1825.8

616

1731.0

1826.0

617

1731.2

1826.2

618

1731.4

1826.4

619

1731.6

1826.6

620

1731.8

1826.8

621

1732.0

1827.0

622

1732.2

1827.2

623

1732.4

1827.4

624

1732.6

1827.6

625

1732.8

1827.8

626

1733.0

1828.0

627

1733.2

1828.2

628

1733.4

1828.4

629

1733.6

1828.6

630

1733.8

1828.8

631

1734.0

1829.0

632

1734.2

1829.2

633

1734.4

1829.4

634

1734.6

1829.6

635

1734.8

1829.8

636

1735.0

1830.0

637

1735.2

1830.2

638

1735.4

1830.4

639

1735.6

1830.6

640

1735.8

1830.8

641

1736.0

1831.0

642

1736.2

1831.2

643

1736.4

1831.4

644

1736.6

1831.6

645

1736.8

1831.8

646

1737.0

1832.0

647

1737.2

1832.2

648

1737.4

1832.4

649

1737.6

1832.6

650

1737.8

1832.8

651

1738.0

1833.0

652

1738.2

1833.2

653

1738.4

1833.4

654

1738.6

1833.6

655

1738.8

1833.8

656

1739.0

1834.0

657

1739.2

1834.2

658

1739.4

1834.4

659

1739.6

1834.6

660

1739.8

1834.8

661

1740.0

1835.0

662

1740.2

1835.2

663

1740.4

1835.4

664

1740.6

1835.6

665

1740.8

1835.8

666

1741.0

1836.0

667

1741.2

1836.2

668

1741.4

1836.4

669

1741.6

1836.6

670

1741.8

1836.8

671

1742.0

1837.0

672

1742.2

1837.2

673

1742.4

1837.4

674

1742.6

1837.6

675

1742.8

1837.8

676

1743.0

1838.0

677

1743.2

1838.2

678

1743.4

1838.4

679

1743.6

1838.6

680

1743.8

1838.8

681

1744.0

1839.0

682

1744.2

1839.2

683

1744.4

1839.4

684

1744.6

1839.6

685

1744.8

1839.8

686

1745.0

1840.0

687

1745.2

1840.2

688

1745.4

1840.4

689

1745.6

1840.6

690

1745.8

1840.8

691

1746.0

1841.0

692

1746.2

1841.2

693

1746.4

1841.4

694

1746.6

1841.6

695

1746.8

1841.8

696

1747.0

1842.0

697

1747.2

1842.2

698

1747.4

1842.4

699

1747.6

1842.6

700

1747.8

1842.8

701

1748.0

1843.0

702

1748.2

1843.2

703

1748.4

1843.4

704

1748.6

1843.6

705

1748.8

1843.8

706

1749.0

1844.0

707

1749.2

1844.2

708

1749.4

1844.4

709

1749.6

1844.6

710

1749.8

1844.8

711

1750.0

1845.0

712

1750.2

1845.2

713

1750.4

1845.4

714

1750.6

1845.6

715

1750.8

1845.8

716

1751.0

1846.0

717

1751.2

1846.2

718

1751.4

1846.4

719

1751.6

1846.6

720

1751.8

1846.8

721

1752.0

1847.0

722

1752.2

1847.2

723

1752.4

1847.4

724

1752.6

1847.6

725

1752.8

1847.8

726

1753.0

1848.0

727

1753.2

1848.2

728

1753.4

1848.4

729

1753.6

1848.6

730

1753.8

1848.8

731

1754.0

1849.0

732

1754.2

1849.2

733

1754.4

1849.4

734

1754.6

1849.6

735

1754.8

1849.8

736

1755.0

1850.0

737

1755.2

1850.2

738

1755.4

1850.4

739

1755.6

1850.6

740

1755.8

1850.8

741

1756.0

1851.0

742

1756.2

1851.2

743

1756.4

1851.4

744

1756.6

1851.6

745

1756.8

1851.8

746

1757.0

1852.0

747

1757.2

1852.2

748

1757.4

1852.4

749

1757.6

1852.6

750

1757.8

1852.8

751

1758.0

1853.0

752

1758.2

1853.2

753

1758.4

1853.4

754

1758.6

1853.6

755

1758.8

1853.8

756

1759.0

1854.0

757

1759.2

1854.2

758

1759.4

1854.4

759

1759.6

1854.6

760

1759.8

1854.8

761

1760.0

1855.0

762

1760.2

1855.2

763

1760.4

1855.4

764

1760.6

1855.6

765

1760.8

1855.8

766

1761.0

1856.0

767

1761.2

1856.2

768

1761.4

1856.4

769

1761.6

1856.6

770

1761.8

1856.8

771

1762.0

1857.0

772

1762.2

1857.2

773

1762.4

1857.4

774

1762.6

1857.6

775

1762.8

1857.8

776

1763.0

1858.0

777

1763.2

1858.2

778

1763.4

1858.4

779

1763.6

1858.6

780

1763.8

1858.8

781

1764.0

1859.0

782

1764.2

1859.2

783

1764.4

1859.4

784

1764.6

1859.6

785

1764.8

1859.8

786

1765.0

1860.0

787

1765.2

1860.2

788

1765.4

1860.4

789

1765.6

1860.6

790

1765.8

1860.8

791

1766.0

1861.0

792

1766.2

1861.2

793

1766.4

1861.4

794

1766.6

1861.6

795

1766.8

1861.8

796

1767.0

1862.0

797

1767.2

1862.2

798

1767.4

1862.4

799

1767.6

1862.6

800

1767.8

1862.8

801

1768.0

1863.0

802

1768.2

1863.2

803

1768.4

1863.4

804

1768.6

1863.6

805

1768.8

1863.8

806

1769.0

1864.0

807

1769.2

1864.2

808

1769.4

1864.4

809

1769.6

1864.6

810

1769.8

1864.8

811

1770.0

1865.0

812

1770.2

1865.2

813

1770.4

1865.4

814

1770.6

1865.6

815

1770.8

1865.8

816

1771.0

1866.0

817

1771.2

1866.2

818

1771.4

1866.4

819

1771.6

1866.6

820

1771.8

1866.8

821

1772.0

1867.0

822

1772.2

1867.2

823

1772.4

1867.4

824

1772.6

1867.6

825

1772.8

1867.8

826

1773.0

1868.0

827

1773.2

1868.2

828

1773.4

1868.4

829

1773.6

1868.6

830

1773.8

1868.8

831

1774.0

1869.0

832

1774.2

1869.2

833

1774.4

1869.4

834

1774.6

1869.6

835

1774.8

1869.8

836

1775.0

1870.0

837

1775.2

1870.2

838

1775.4

1870.4

839

1775.6

1870.6

840

1775.8

1870.8

841

1776.0

1871.0

842

1776.2

1871.2

843

1776.4

1871.4

844

1776.6

1871.6

845

1776.8

1871.8

846

1777.0

1872.0

847

1777.2

1872.2

848

1777.4

1872.4

849

1777.6

1872.6

850

1777.8

1872.8

851

1778.0

1873.0

852

1778.2

1873.2

853

1778.4

1873.4

854

1778.6

1873.6

855

1778.8

1873.8

856

1779.0

1874.0

857

1779.2

1874.2

858

1779.4

1874.4

859

1779.6

1874.6

860

1779.8

1874.8

861

1780.0

1875.0

862

1780.2

1875.2

863

1780.4

1875.4

864

1780.6

1875.6

865

1780.8

1875.8

866

1781.0

1876.0

867

1781.2

1876.2

868

1781.4

1876.4

869

1781.6

1876.6

870

1781.8

1876.8

871

1782.0

1877.0

872

1782.2

1877.2

873

1782.4

1877.4

874

1782.6

1877.6

875

1782.8

1877.8

876

1783.0

1878.0

877

1783.2

1878.2

878

1783.4

1878.4

879

1783.6

1878.6

880

1783.8

1878.8

881

1784.0

1879.0

882

1784.2

1879.2

883

1784.4

1879.4

884

1784.6

1879.6

885

1784.8

1879.8





< Frequency Table for PCS 1900>

ARFCN

fl(UL)

fu(DL)

512

1850.2

1930.2

513

1850.4

1930.4

514

1850.6

1930.6

515

1850.8

1930.8

516

1851.0

1931.0

517

1851.2

1931.2

518

1851.4

1931.4

519

1851.6

1931.6

520

1851.8

1931.8

521

1852.0

1932.0

522

1852.2

1932.2

523

1852.4

1932.4

524

1852.6

1932.6

525

1852.8

1932.8

526

1853.0

1933.0

527

1853.2

1933.2

528

1853.4

1933.4

529

1853.6

1933.6

530

1853.8

1933.8

531

1854.0

1934.0

532

1854.2

1934.2

533

1854.4

1934.4

534

1854.6

1934.6

535

1854.8

1934.8

536

1855.0

1935.0

537

1855.2

1935.2

538

1855.4

1935.4

539

1855.6

1935.6

540

1855.8

1935.8

541

1856.0

1936.0

542

1856.2

1936.2

543

1856.4

1936.4

544

1856.6

1936.6

545

1856.8

1936.8

546

1857.0

1937.0

547

1857.2

1937.2

548

1857.4

1937.4

549

1857.6

1937.6

550

1857.8

1937.8

551

1858.0

1938.0

552

1858.2

1938.2

553

1858.4

1938.4

554

1858.6

1938.6

555

1858.8

1938.8

556

1859.0

1939.0

557

1859.2

1939.2

558

1859.4

1939.4

559

1859.6

1939.6

560

1859.8

1939.8

561

1860.0

1940.0

562

1860.2

1940.2

563

1860.4

1940.4

564

1860.6

1940.6

565

1860.8

1940.8

566

1861.0

1941.0

567

1861.2

1941.2

568

1861.4

1941.4

569

1861.6

1941.6

570

1861.8

1941.8

571

1862.0

1942.0

572

1862.2

1942.2

573

1862.4

1942.4

574

1862.6

1942.6

575

1862.8

1942.8

576

1863.0

1943.0

577

1863.2

1943.2

578

1863.4

1943.4

579

1863.6

1943.6

580

1863.8

1943.8

581

1864.0

1944.0

582

1864.2

1944.2

583

1864.4

1944.4

584

1864.6

1944.6

585

1864.8

1944.8

586

1865.0

1945.0

587

1865.2

1945.2

588

1865.4

1945.4

589

1865.6

1945.6

590

1865.8

1945.8

591

1866.0

1946.0

592

1866.2

1946.2

593

1866.4

1946.4

594

1866.6

1946.6

595

1866.8

1946.8

596

1867.0

1947.0

597

1867.2

1947.2

598

1867.4

1947.4

599

1867.6

1947.6

600

1867.8

1947.8

601

1868.0

1948.0

602

1868.2

1948.2

603

1868.4

1948.4

604

1868.6

1948.6

605

1868.8

1948.8

606

1869.0

1949.0

607

1869.2

1949.2

608

1869.4

1949.4

609

1869.6

1949.6

610

1869.8

1949.8

611

1870.0

1950.0

612

1870.2

1950.2

613

1870.4

1950.4

614

1870.6

1950.6

615

1870.8

1950.8

616

1871.0

1951.0

617

1871.2

1951.2

618

1871.4

1951.4

619

1871.6

1951.6

620

1871.8

1951.8

621

1872.0

1952.0

622

1872.2

1952.2

623

1872.4

1952.4

624

1872.6

1952.6

625

1872.8

1952.8

626

1873.0

1953.0

627

1873.2

1953.2

628

1873.4

1953.4

629

1873.6

1953.6

630

1873.8

1953.8

631

1874.0

1954.0

632

1874.2

1954.2

633

1874.4

1954.4

634

1874.6

1954.6

635

1874.8

1954.8

636

1875.0

1955.0

637

1875.2

1955.2

638

1875.4

1955.4

639

1875.6

1955.6

640

1875.8

1955.8

641

1876.0

1956.0

642

1876.2

1956.2

643

1876.4

1956.4

644

1876.6

1956.6

645

1876.8

1956.8

646

1877.0

1957.0

647

1877.2

1957.2

648

1877.4

1957.4

649

1877.6

1957.6

650

1877.8

1957.8

651

1878.0

1958.0

652

1878.2

1958.2

653

1878.4

1958.4

654

1878.6

1958.6

655

1878.8

1958.8

656

1879.0

1959.0

657

1879.2

1959.2

658

1879.4

1959.4

659

1879.6

1959.6

660

1879.8

1959.8

661

1880.0

1960.0

662

1880.2

1960.2

663

1880.4

1960.4

664

1880.6

1960.6

665

1880.8

1960.8

666

1881.0

1961.0

667

1881.2

1961.2

668

1881.4

1961.4

669

1881.6

1961.6

670

1881.8

1961.8

671

1882.0

1962.0

672

1882.2

1962.2

673

1882.4

1962.4

674

1882.6

1962.6

675

1882.8

1962.8

676

1883.0

1963.0

677

1883.2

1963.2

678

1883.4

1963.4

679

1883.6

1963.6

680

1883.8

1963.8

681

1884.0

1964.0

682

1884.2

1964.2

683

1884.4

1964.4

684

1884.6

1964.6

685

1884.8

1964.8

686

1885.0

1965.0

687

1885.2

1965.2

688

1885.4

1965.4

689

1885.6

1965.6

690

1885.8

1965.8

691

1886.0

1966.0

692

1886.2

1966.2

693

1886.4

1966.4

694

1886.6

1966.6

695

1886.8

1966.8

696

1887.0

1967.0

697

1887.2

1967.2

698

1887.4

1967.4

699

1887.6

1967.6

700

1887.8

1967.8

701

1888.0

1968.0

702

1888.2

1968.2

703

1888.4

1968.4

704

1888.6

1968.6

705

1888.8

1968.8

706

1889.0

1969.0

707

1889.2

1969.2

708

1889.4

1969.4

709

1889.6

1969.6

710

1889.8

1969.8

711

1890.0

1970.0

712

1890.2

1970.2

713

1890.4

1970.4

714

1890.6

1970.6

715

1890.8

1970.8

716

1891.0

1971.0

717

1891.2

1971.2

718

1891.4

1971.4

719

1891.6

1971.6

720

1891.8

1971.8

721

1892.0

1972.0

722

1892.2

1972.2

723

1892.4

1972.4

724

1892.6

1972.6

725

1892.8

1972.8

726

1893.0

1973.0

727

1893.2

1973.2

728

1893.4

1973.4

729

1893.6

1973.6

730

1893.8

1973.8

731

1894.0

1974.0

732

1894.2

1974.2

733

1894.4

1974.4

734

1894.6

1974.6

735

1894.8

1974.8

736

1895.0

1975.0

737

1895.2

1975.2

738

1895.4

1975.4

739

1895.6

1975.6

740

1895.8

1975.8

741

1896.0

1976.0

742

1896.2

1976.2

743

1896.4

1976.4

744

1896.6

1976.6

745

1896.8

1976.8

746

1897.0

1977.0

747

1897.2

1977.2

748

1897.4

1977.4

749

1897.6

1977.6

750

1897.8

1977.8

751

1898.0

1978.0

752

1898.2

1978.2

753

1898.4

1978.4

754

1898.6

1978.6

755

1898.8

1978.8

756

1899.0

1979.0

757

1899.2

1979.2

758

1899.4

1979.4

759

1899.6

1979.6

760

1899.8

1979.8

761

1900.0

1980.0

762

1900.2

1980.2

763

1900.4

1980.4

764

1900.6

1980.6

765

1900.8

1980.8

766

1901.0

1981.0

767

1901.2

1981.2

768

1901.4

1981.4

769

1901.6

1981.6

770

1901.8

1981.8

771

1902.0

1982.0

772

1902.2

1982.2

773

1902.4

1982.4

774

1902.6

1982.6

775

1902.8

1982.8

776

1903.0

1983.0

777

1903.2

1983.2

778

1903.4

1983.4

779

1903.6

1983.6

780

1903.8

1983.8

781

1904.0

1984.0

782

1904.2

1984.2

783

1904.4

1984.4

784

1904.6

1984.6

785

1904.8

1984.8

786

1905.0

1985.0

787

1905.2

1985.2

788

1905.4

1985.4

789

1905.6

1985.6

790

1905.8

1985.8

791

1906.0

1986.0

792

1906.2

1986.2

793

1906.4

1986.4

794

1906.6

1986.6

795

1906.8

1986.8

796

1907.0

1987.0

797

1907.2

1987.2

798

1907.4

1987.4

799

1907.6

1987.6

800

1907.8

1987.8

801

1908.0

1988.0

802

1908.2

1988.2

803

1908.4

1988.4

804

1908.6

1988.6

805

1908.8

1988.8

806

1909.0

1989.0

807

1909.2

1989.2

808

1909.4

1989.4

809

1909.6

1989.6

810

1909.8

1989.8





< Frequency Table for GSM 450 >

ARFCN

fl(UL)

fu(DL)

259

450.6

460.6

260

450.8

460.8

261

451.0

461.0

262

451.2

461.2

263

451.4

461.4

264

451.6

461.6

265

451.8

461.8

266

452.0

462.0

267

452.2

462.2

268

452.4

462.4

269

452.6

462.6

270

452.8

462.8

271

453.0

463.0

272

453.2

463.2

273

453.4

463.4

274

453.6

463.6

275

453.8

463.8

276

454.0

464.0

277

454.2

464.2
